Overview:

• Max. Voltage Between Terminals And Earth Ground: 1000V DC or AC
• Measuring method: Dual-slope integration A/D converter
• Sampling Time: approx. 0.4 second
• Display: 22mm LCD
• Show Value: 1999 (3 1/2)
• Polarity Indication: ‘-’indicates negative polarity.
• Overrange Indication: Display ‘1’ or ‘-1’
• Unit showing: showing of function and electrical capacity.
• Power Supply: 1.5V×6 (size AA) batter (recommended to use the alkaline or heavy duty battery.)
• Power Consumption:
• 5mA（DC1000V、AC750V、200Ω、）
• 30mA（200MΩ/250V）
• 50mA（200MΩ/500V）
• 100mA（2000MΩ/1000V）
• Low Battery Indication: ‘’ displayed
• Operating Temperature: 0℃ to 40℃（32°F to 104°F）
• Operating Humidity: ≤85%RH
• Storage Temperature: -10℃ to 50℃（10°F to 122°F）
• Dimension: 192×122×55 mm
• Weight: Approx. 545g（including battery)
• Certificate: CAT III 1000V/CAT III 600V RoHS
