Brand: Rice Lake
Categories: Indicators & Controllers
0,00 AED (Excl. VAT)
Brand: Rice Lake
Categories: Indicators & Controllers
0,00 AED (Excl. VAT)
Tags: Petrascale
Power: AC voltages: 100-240 VAC; 50-60 Hz DC voltages: 11-30 VDC Consumption: 60WExcitation Voltage: 10 ± 0.5 VDC 16 x 350Ω or 32 x 700Ω load cells per A/D card Analog Signal Input Range: Analog Signal Sensitivity: A/D Sample Rate: Resolution: System Linearity Digital I/O: |
Communication Ports: Port 1 & 2: Full duplex RS-232 with CTS/RTS, RS-422/485 Baud Rate: 1200 to 115200 Port 3: USB 2.0 Device (Micro) Port 4: Bluetooth® SPP 2.1+EDR USB Host: (2) Type A Connectors max 500 mA Ethernet: Wired 10/100 Auto-MDX Ethernet: Wireless 802.11 b/g/n 2.4GHzOnboard: Selectable filters: Three stage, Adaptive or Damping Embedded Linux® OS 8 GB eMMC (system use) 1 GB DDR3 RAM 460 MB onboard database (SQLite) storage Up to 32 GB micro SD card (sold separately)Display: Seven-inch, 800 x 480 pixel, 500 or 1,000 NIT Twelve-inch, 1280 x 800 pixel, 1,500 NIT Keys/Buttons: |
Temperature Range: Certified: 14°F to 104°F (-10°C to 40˚C) Operating: -4°F to 131°F (-20°C to 55˚C)Weight: Universal enclosure: 11 lb (4.9 kg) Panel mount enclosure: 8 lb (3.6 kg) Wall mount enclosure: 23 lb (10.4 kg) Panel mount 7 in touch-only: 7 lb (3.1 kg) Panel mount 12 in touch-only: 10 lb (4.5 kg) Rating/Material: Warranty: EMC Immunity: Approvals: |
Six option slots that support:
Universal (1280-2) Dimensions | |||||
---|---|---|---|---|---|
A | 10.86 in (276 mm) | D | 4.97 in (126 mm) | G | 5.25 in (133 mm) |
B | 6.22 in (158 mm) | E | 9.00 in (229 mm) | ||
C | 9.24 in (235 mm) | F | 12.50 in (318 mm) |
Wall Mount (1280-3) Dimensions | |||||
---|---|---|---|---|---|
A | 14.92 in (379 mm) | D | 18.84 in (479 mm) | G | 8.08 in (205 mm) |
B | 11.00 in (279 mm) | E | 19.64 in (499 mm) | ||
C | 18.22 in (463 mm) | F | 14.20 in (361 mm) |
Panel Mount (1280-4) Dimensions | |||
---|---|---|---|
A | 9.00 in (229 mm) | D | 5.34 in (136 mm) |
B | 9.00 in (229 mm) | E | 0.32 in (8 mm) |
C | 0.58 in (15 mm) |
7-inch Touch-only (1280-5) Dimensions | 12-inch Touch-only (1280-6) Dimensions | ||
---|---|---|---|
A | 9.00 in (229 mm) | A | 14.00 in (356 mm) |
B | 6.22 in (158 mm) | B | 10.00 in (254 mm) |
