DH Series is an advanced Floor scale with high resolution and various functions. It is suitable for use in all type of heavy industries.
Features:
- Display: Extra Large (XL) LED 51mm
- ABS Plastic
- Functions: Hold, Accumulation, TARE, Zero, Check Weight with alarm, Auto Calibration, Auto Zero, livestock stabilization, Illumination Level, Auto off
- Interface: Serial RS232
Model Number | Capacities | Division |
DH | Open | Open |
CAS DH Weighing Indicator. With fast speed and high precision, A/D conversion technology, the DH Series is suitable for either a bench platform scale, floor scale or any static check-weighing system that is equipped with 1~4 load cells. With a built-in rechargeable battery, the DH Series can operate in environments where little or no power outlets are available.
- Large Display
- Rechargeable battery
- Check-weighing function with alarm for Hi & Lo
- 1/3,000 External resolution
- 10 times/sec A/D conversion speed
- Built-in rechargeable battery
- Communication interface: RS-232C & Current loop
- Lb/kg switchable
- Hold,
- Accumulation
- TARE
- Zero
- Counting
- Auto Calibration
- Auto Zero
Model | DH |
Loadcell Excitation voltage | DC 5V |
Loadcell connection(350 Ω) | Max. 4ea |
Input signal range | -19mV ~ 19mV |
Extenal resolution | 1/3,000 |
A/D Conversion speed | 10 times/sec |
Display | LED |
Character size | 51mm(Height) |
Key | 6 function keys |
Power | DC5V rechargeable battery |
AC220V / 50, 60Hz | |
Battery life time | Approx. 30 hours |
Battery charging time | Approx. 15 hours |
Operating temperature | 0˚C ~ 40 ˚C |
Dimension(mm) | 236(W) x 167.5(D) x 161.2 (H) |
Product weight(kg) | Approx. 2 |
Interface(1 port) | RS-232C |
Current loop |
