Features:
- Display: 2000 counts
- Data Logging: 16000 records
- Auto Ranging
- Auto Power Off
- AC Singal Output: 0.707 Vrms at FS (Auto-range mode isn’t included) Output impedance approx.600Ω
- DC Singal Output: 10mV/dB Output impedance approx.100Ω
- AC Adapter
– Voltage 9VDC
– Voltage Ripple <100m Vpp
– Supple Current >100m ADC
– Socket: pin Ground
– Casing Positive
– External Diameter 3.5mm
- Fast
- Low
- A Weighting
- B Weighting
- Date and Time Display
- MAX
- Data Hold
- Display Backlight
- Low Battery Display
- Analog Bar Indication
- Over Range Indication
- RS-232 Pclink
- USB Interface
