Brand:

UT352 Sound Level Meter

Call for price

[posbadges]

UT300 series infrared thermometers are lightweight and small. Objects can be quickly and accurately measured from a distance with 0.1°C resolution. These devices consume very little power, suitable for indoor and outdoor use.

GET QUOTATION

Brand:

UT352 Sound Level Meter

Call for price

[posbadges]

UT300 series infrared thermometers are lightweight and small. Objects can be quickly and accurately measured from a distance with 0.1°C resolution. These devices consume very little power, suitable for indoor and outdoor use.

[showcdownloadbuttoninspp]
[showmdownloadbuttoninspp]
GET QUOTATION
[woocommerce_variations_table]

Features

  • MAX/MIN modes
  • Auto power off (cancelable)
  • 63 sets data storage
  • AC/DC analog signal output
  • Over/under range indication
  • Data hold, LCD backlight
  • Simulated analog bar
  • A (ear)/C (machine) weighting modes
  • Manual/auto range selectable
  • Fast/slow response rate (fast: 125ms, slow: 1s)
  • Powered by batteries or external power source

Specifications

Specifications Range Best Accuracy
Model   UT352
Range 30~80dB ±1.5dB
50~100dB ±1.5dB
60~110dB ±1.5dB
80~130dB ±1.5dB
Frequency  31.5Hz~8000Hz √
Frequency Weighting A&C √
Sample Rate FAST: 8 Times/s √
SLOW: 1 Times/s √
Features
Analogue Outputs AC: 0.707Vrms full scale; Output impedance: around 600Ω  √
DC: 2Vrms full scale; 10mV/dB; Output impedance: around 100Ω  √
Data Hold   √
Auto Power Off   √
Low Battery Indication ≤4.8V √
MAX Mode   √
MIN Mode   √
Data Logging   63
High Alarm Display “OVER” √
Lower Alarm Display “UNDER” √
LCD Backlight   √
Analog Bar Graph 30~130dB √
General Characteristics
Power 1.5V Batteries (LR6) X 4
LCD Size 53mm X 41mm
Product Color Red and Grey
Product Net Weight 330g
Product Size 273mm X 70mm X 39mm
Standard Accessories Batteries, Windscreen, Leather Box
Standard Individual Packing Gift Box, English Manual
Standard Quantity Per Carton 30pcs
Standard Carton Measurement 670mm X 385mm X 300mm (0.077 CBM Per Standard Carton)
Standard Carton Gross Weight 18kg



Additional information

Model

UT352
