• Minimum load cell verification interval: Vmin = EMax / 10000
• Full Scale Output: 2mV/V +/- 0,5%
• Non-Repeatability: 0,01% F.S.
• Combined Error 0,05%
• Temperature effect on zero: 0,02% / 10°C
• Temperature effect on full scale output: 0,02% / 10°C
• Compensated Temperature Range: -10°C/+40°C
• Operating Temperature Range: -20°C/+60°C
• Creep error after 30 minutes: 0,02% F.S.
• Maximum tolerated excitation voltage: 15 Vdc
• Input Resistance: 750 ± 10 Ohm
• Output Resistance: 700 ± 5 Ohm
• Zero Balance: +/-1% F.S.
• Insulation Resistance: >5000 MOhm
• Safe Overload: 120% F.S.
• 4-wire shielded cable, 5 mm diameter:
  – 5 m long for CPX 250…5000 versions;
  – 10 m long for CPX 7500…100000 versions.

Applications

Tanks and hoppers
